0.5w 5v 100ma Mini Small Solar Panel Module DIY Polysilicon Solar Epoxy

0.5w 5v 100ma Mini Small Solar Panel Module DIY Polysilicon Solar Epoxy Cell Charger B016

DIY YOUR OWN SMART MODEL----Build your own powered models, solar toys, solar lights, solar displays, charging small DC batteries. It can be used for teaching purpose. Many of our customers come from school, colleague, etc.

BLOCKING DIODE INSTALLED ----A blocking diode installed already in the backside to protect the solar panel from over-charging and current backflow.

HIGH QUALITY & EASY USE---- High quality epoxy resin, unique technology to make the components beautiful and strong, anti-wind and snow, increase the service life of solar panels. Color coded wires with alligator clips make working with it easy and fun. For those of you who want to connect more than one panel together, this panel has two soldered tabs for permanent connections.

EDUCATION---- Solar panels are devices that absorb sunlight and convert solar radiation directly or indirectly into electricity through photoelectric or photochemical effects, it's perfect devices for science project.

CONNECT SOLAR PANELS IN PARALLEL OR IN SERIES---- When the voltage of your solar panel doesn’t satisfy your storage battery, you can take two or more same solar panels together in series. Such as, two 5.5v solar panel connect together in series, so its voltage is 11V. When the voltage of solar panel satisfies your storage battery. In order to speed up the rate of charge, you can take two or more same solar panel together parallel connection

Designed exclusively for ease of use at home, school, lab, or workshop, this panel is perfect for your solar projects.
At 0.5W, you can charge AA batteries, drive white LED,or your portable radio.
Color coded wires with alligator clips make working with it easy and fun. For those of you who want to connect more than one panel together, this panel has two soldered tabs for permanent connections Parameters
Model Number: GP80*80-10A100
Material: Monocrystalline Silicon
Number of Cells: 10
Max. power: 0.5W
Max. current: 100mA
Max. voltage: 5V
Size: 80mm*80mm/3.15in*3.15in
Weight: 50g/1.76oz Features:
1.4 holes at for extreme corner for holding screw, at 2mm diameter.
2.Red/black 3 feet long wire, connected as one wire. 3.Colored alligator clips soldered in the backside
4.Blocking diode installed already in the back to protect the solar panel from over-charging and current backflow.
5.Put a plastic cover in the panel, a label stick there said "please remove protective cover"
6.Special silicone to protect the blocking diode well to prevent the humid climates. Package Content:
1*Solar Panel (alligator clips soldered in the backside) Storage Battery Solar Panel
1.2V                     2.0V ~ 2.5V
2.4V                     3.5V ~ 4.0V
3.6V                    5.0V ~ 6.0V
6.0V                    7.5V ~ 9.0V
12.0V                 15.0V ~18.0V Shipping
